2,000 HP LS - Complete Engine

Our 2,000hp LS package is a complete race engine that makes real power, with reliability. This is a fully-filled iron block, max effort setup that runs on Methanol.

Priced at $45,000, which includes an engine assembled from the billet Dailey dry sump pan to valve cover equipped with CM quick release burn down fittings.   A cam driven mechanical fuel pump, the necessary drive components, and a set of Billet Atomizer injectors are included as well.  An initial tune will also be provided if using Holley EFI.  Using reliable components from companies we have personal experience with, we can build an engine that provides you with wins and confidence.

PARTS LIST:

Short Block

• Dart LS Next2 Pro Iron (next2 option upgrades to 1/2" main studs)
• MGPPRO MGP connecting rods
• CUSTOM Diamond Pistons w/ pins and rings
• CUSTOM billet CCW crankshaft (Crower, Callies, Bryant, or Winberg based on availability)
• Dart Cam bearing set
• King XP and/or Clevite H bearings
• Block filler

Short Block – Features/Labor

• Assembly of short block w/ file fit rings
• Clearance block for rods when necessary
• Labor to machine block for top fuel hoops, bore/hone, line bore/hone, final balance rotating assembly, mill deck, machine for ½” studs, .903 lifters, etc
•


Valvetrain

• Isky red zone or BAM solid roller lifters
• Brodix BP BR 7 BS heads solid casting, with PAC or PSI springs, Ti intake valves, Inconel exhaust, HIP’d
• T&D or Jesel shaft rocker system
• Trend custom length 7/16” pushrods
• Comp or Manley double roller billet timing set
• Joe Blow billet timing cover and drive spud for cam driven fuel pump
• Custom 8620 Cam Motion / JAC camshaft

Oiling and Gaskets

• Clark Copper head gaskets
• Dailey Dry sump system w/ pan, 6 stage pump (1 stage for turbo scavenge)

Other

• GM camshaft position sensor
• Tick billet valley cover
• ATI Super Damper
• ATI dry sump mandrel
• Jones Racing pullies for oil pump drive
• Holley tall valve covers
• Cunningham Machine billet burn down tubes

Fueling

• CUSTOM Billet Atomizer injectors
• Aeromotive Spur Gear fuel pump and fittings
• Aeromotive billet fuel pump mounting bracket

Long Block – Features/Labor

• CNC head decks, chamber soften, and top fuel hoop
• Assemble/setup cylinder heads
• Installing/degree cam, installing heads and valve train, installing pan, covers
• Complete assembly
